| MARCA | GIGABYTE | |
| MODELO | B650M DS3H | |
| REVISION | 1.0 | |
| CHIPSET | AMD B650 | |
| TIPO DE SOCKET | AM5 AMD | |
| PROCESADORES | AMD COMPATIBLE | Procesador AMD Ryzen 9 SAM5 7XXX
Procesador AMD Ryzen 7 SAM5 7XXX
Procesador AMD Ryzen 5 SAM5 7XXX
| |
| MEMORIAS RAM | COMPATIBLES | Memoria RAM DDR5 6000 MHz PC5-48000
Memoria RAM DDR5 5600 MHz PC5-44800
Memoria RAM DDR5 5200 MHz PC5-41600
Memoria RAM DDR5 4800 MHz PC5-38400
| | NUMERO DE SOCKETS DIMM | 4 | | EXPANSION MAXIMA EN GB | 128 | | TECNOLOGIA | AMD EXPO
Intel XMP
Dual Channel
| | TIPO DE RAM | DDR5 | |
| VIDEO | Revisar caracteristicas del Procesador | |
| SONIDO | TECNOLOGIA | High Definition (HD) | | CHIPSET | Realtek Audio Codec
| | CANALES | 7.1 | |
| CONECTIVIDAD | ETHERNET | CHIPSET | Realtek 2.5GbE
| | VELOCIDAD | 100 Mbps
1000 Mbps
2500 Mbps
| |
| ALMACENAMIENTO SERIAL ATA | NUMERO DE PUERTOS | 4 | | VELOCIDAD DE TRANSFERENCIA | 6 Gbit/s
| | RAID SATA | RAID 10
RAID 1
RAID 0
| |
| ALMACENAMIENTO M.2 | NUMERO TOTAL DE SLOTS M.2 KEY M | 2 | | DISTRIBUCION DE SLOTS M.2 KEY M | M.2 CONECTADO AL PROCESADOR | 2 PCIe 4.0 x4, tipos 2280/25110
| | RAID PCIE O NVME | RAID 1
RAID 0
| |
| SLOTS DE EXPANSION | CONECTADO AL PROCESADOR | 1 PCI Express x16 slot, PCIe 4.0 modo x16
| | CONECTADO AL CHIPSET | 1 PCI Express x1 slot, PCIe 3.0
| |
| PUERTOS INTERNOS | FRONT PANEL AUDIO HEADER | 1 | | USB 3.2 GEN 2 TIPO-C HEADER | 1 | | USB 3.2 GEN 1 HEADER | 2 | | USB 2.0 / 1.1 HEADER | 4 | |
| PUERTOS BACK PANEL | USB 3.2 GEN 2 TIPO-C | 1 | | USB 3.2 GEN 2 TIPO-A | 1 | | USB 3.2 GEN 1 TIPO-A | 2 | | USB 2.0 TIPO-A | 4 | | HDMI | 1 | | DISPLAYPORT | 2 | | RJ-45 | 1 | | AUDIO JACKS | 3 | | PS/2 COMBO | 1 | | Q-FLASH PLUS | 1 | |
| BIOS | AMI BIOS UEFI | |
| FACTOR DE FORMA Y DIMENSIONES | FACTOR DE FORMA | Micro-ATX | | DIMENSIONES | 24.4cm x 24.4cm | |
| PRESENTACION | CAJA | |
| CONECTORES FUENTE POWER | 1 x 24-pin ATX Main Power | 1 | | 1 x 8-pin ATX 12V power | 1 | |
|
|
